Allvent 180MM Cabinet Fan

The Allvent ALVUF18JC23-BTHD ALV117 is a heavy-duty 180mm cabinet fan designed for commercial ventilation and equipment cooling applications where strong continuous airflow is required. It features an aluminium casing, ball-bearing motor and a service life rated at over 40,000 running hours, making it suitable for larger electrical cabinets, control panels and enclosed equipment spaces. With airflow up to 781 m³/h, it is the highest-capacity model in this Allvent cabinet fan range and is well suited to applications where significant heat removal is required.

Cabinet fan
180 x 180 x 90mm dimensions
240V
50Hz
75W
Single phase
Airflow 217 L/s
Airflow 781 m³/h
Sound level 54dBA at 3m
Aluminium casing
Ball bearing motor
Over 40,000 running hours
High quality, proven reliability
Metal finger guards available
Plastic finger guards available
Filters available
Suitable for electrical cabinets
Suitable for control panels
Suitable for larger equipment cooling applications
Suitable for commercial ventilation systems

Click here for Data Sheet

SKU	ALV117
Brand	Allvent

Be The First To Review This Product!

Help other Alstra Electrical Wholesalers users shop smarter by writing reviews for products you have purchased.

Write a product review
