Allvent 92MM Cabinet Fan

The Allvent ALVUF92A23-BTH ALV114 is a compact 92mm cabinet fan designed for commercial ventilation and equipment cooling applications where reliable continuous airflow is required. It features an aluminium casing, ball-bearing motor and a service life rated at over 40,000 running hours, making it well suited to electrical cabinets, control panels and other enclosed equipment spaces. With airflow up to 78 m³/h and a compact 92 x 92 x 38mm body, it provides dependable cooling in confined installations.

Cabinet fan
92 x 92 x 38mm dimensions
240V
50Hz
16W
Single phase
Airflow 22 L/s
Airflow 78 m³/h
Sound level 34dBA at 3m
Aluminium casing
Ball bearing motor
Over 40,000 running hours
High quality, proven reliability
Metal finger guards available
Plastic finger guards available
Filters available
Suitable for electrical cabinets
Suitable for control panels
Suitable for equipment cooling applications

Click here for Data Sheet

SKU	ALV114
Brand	Allvent
