Trader Dimpala 400W Universal Rotary Push Button LED Dimmer

The Trader Dimpala DIMR is a universal rotary push button dimmer designed for smooth control of dimmable LED lighting while also offering compatibility with incandescent, 12V halogen and dimmable CFL lamps. Its push-to-switch and rotary dimming design makes everyday lighting control simple, while the integrated two-way switching mechanism can also be used in three-way configurations with an intermediate switch. With a low 2W minimum load, adjustable minimum and maximum brightness, soft start operation and selectable green, blue or off backlighting, it is a flexible option for living rooms, bedrooms, dining areas, kitchens, offices and other residential or commercial spaces where reliable wall-mounted dimming is required.

Universal rotary push button dimmer
Push ON/OFF control
Rotary dimming control
Optimised for dimmable LED lamps and drivers
Suitable for incandescent lamps
Suitable for 12V halogen dichroic lamps and transformers
Suitable for dimmable CFL lamps
Minimum load 2W
Maximum load 400W
Adjustable minimum and maximum brightness
Minimum brightness typically 0%
Integrated two-way switch mechanism
Suitable for two-way switching
Can be used in three-way switching with an intermediate switch
Only one dimmer can be connected to the same load
Integrated switch can replace the need for an additional switch
Selectable LED indicator colours in green, blue or off
Soft start helps improve lamp and driver life
Thermal protection via NTC
Ripple signal filtering helps reduce brightness variation
Protection against incompatible loads
Terminal bore diameter 4.1mm
Suitable for Australian wall plate apertures including Trader, HPM and Clipsal
Multiple dimmers require load derating when installed together
Suitable for compatible small motor loads up to 100W

Click here for Data Sheet

SKU	DIMR
Brand	Trader
