NHP DIN-T Miniature Circuit Breaker 32A 2 Pole 6kA D Curve

The NHP DTCB6232D is a 2 pole miniature circuit breaker (MCB) from the DIN-T range, rated at 32A with a D curve trip characteristic. Designed for circuits with high inrush currents, this breaker provides reliable overcurrent and short-circuit protection with a 6kA breaking capacity.

Suitable for commercial and industrial switchboards, the DTCB6232D is ideal for motor loads, transformers and other equipment where a D curve characteristic is required.

  • Rated current: 32A
  • Number of poles: 2
  • Trip curve: D
  • Rated voltage: 415V
  • Frequency: 50–60Hz
  • Voltage type: AC/DC
  • Rated short-circuit breaking capacity (Icn) at 230VAC: 6kA
  • Rated short-circuit breaking capacity (Icn) at 400VAC: 6kA
  • Rated short-circuit breaking capacity (Icu) at 230VAC: 20kA
  • Rated short-circuit breaking capacity (Icu) at 400VAC: 10kA
  • Max rated operational voltage (Ue): 440V
  • Rated insulation voltage (Ui): 440V
  • Rated impulse withstand voltage (Uimp): 6kV
  • Concurrently switching neutral conductor: Yes

Click here for Data Sheet



SKU DTCB6232D
Brand NHP
