NHP DIN-T Miniature Circuit Breaker 16A 2 Pole 10kA D Curve

The NHP DTCB10216D is a high-performance 2 pole miniature circuit breaker (MCB) from the DIN-T range, rated at 16A with a D curve trip characteristic. Designed for industrial and commercial installations, this breaker provides reliable overcurrent and short-circuit protection with a 10kA breaking capacity.

Suitable for AC and DC applications, the DTCB10216D is engineered for demanding circuits where higher inrush currents are present, such as motors and transformers.

  • Rated current: 16A
  • Number of poles: 2
  • Trip curve: D curve
  • Rated voltage: 415V
  • Frequency: 50–60Hz
  • Voltage type: AC/DC
  • Rated short-circuit breaking capacity (Icn) 230VAC: 10kA
  • Rated short-circuit breaking capacity (Icn) 400VAC: 10kA
  • Rated short-circuit breaking capacity (Icu) 230VAC: 15kA
  • Rated short-circuit breaking capacity (Icu) 400VAC: 15kA
  • Rated insulation voltage (Ui): 440V
  • Rated impulse withstand voltage (Uimp): 6kV
  • Concurrently switching neutral conductor: Yes

Click here for Data Sheet

SKU DTCB10216D
Brand NHP
