NHP DIN-T Miniature Circuit Breaker 32A 2 Pole 6kA C Curve

The NHP DTCB6232C is a 2 pole miniature circuit breaker (MCB) from the DIN-T range, rated at 32A with a C curve trip characteristic. Designed for reliable overcurrent and short-circuit protection, this breaker provides a 6kA breaking capacity and is suitable for both AC and DC installations.

Engineered to meet AS/NZS 60898 and AS/NZS 60947-2 standards, the DTCB6232C is ideal for commercial and industrial switchboards where dependable circuit protection is essential.

Rated current: 32A
Number of poles: 2
Trip curve: C curve
Rated voltage: 415V
Frequency: 50–60Hz
Voltage type: AC/DC
Rated short-circuit breaking capacity (Icn) at 230VAC: 6kA
Rated short-circuit breaking capacity (Icn) at 400VAC: 6kA
Rated short-circuit breaking capacity (Icu) at 230VAC: 20kA
Rated short-circuit breaking capacity (Icu) at 400VAC: 10kA
Rated insulation voltage (Ui): 440V
Rated impulse withstand voltage (Uimp): 6kV
Concurrently switching neutral conductor: Yes

Click here for Data Sheet

SKU	DTCB6232C
Brand	NHP
