Tesla 3 Pole Rotary Isolator Switch 63A IP66 Enclosed

The Tesla TES3P63ASME 3 Pole Rotary Isolator Switch is a robust enclosed isolation solution designed for safe and reliable switching in commercial, industrial and general electrical installations. Supplied complete with enclosure, this 63A rotary isolator is built for dependable performance and clear on off operation, making it ideal for applications where secure local isolation is essential. Its enclosed design provides added protection for the switch while delivering a neat and practical finished installation. Built with an insulated polycarbonate enclosure rated to IP66, the TES3P63ASME is suited to demanding environments where protection against dust and water ingress is required. It is pad lockable for added security and features knockout cable entries for simpler installation. The switch is AC23 rated, has a 90 degree switching angle, forced open contacts and terminal screws in the open position. Page 2 of the datasheet shows enclosure dimensions of 155mm wide, 240mm high and 120mm deep, with a total depth of 160mm including the switch mechanism, plus 1 x 20mm and 2 x 25/32mm top and bottom conduit knockouts.

  • 63A enclosed rotary isolator
  • Complete with enclosure
  • Insulated polycarbonate enclosure
  • IP66 weatherproof rating
  • Pad lockable for added security
  • AC23 rated switch
  • 400V 22kW rating
  • 90 degree switching angle
  • Forced open contacts
  • Terminal screws in open position
  • Knockout cable entries
  • 1 x 20mm and 2 x 25/32mm top and bottom conduit knockouts

Click here for Data Sheet

SKU TES3P63ASME
