NHP DIN-T MCB 50A 3 Pole 6kA D Curve

The NHP DTCB6350D is a 3 pole miniature circuit breaker (MCB) from the DIN-T range, rated at 50A with a D curve trip characteristic. Designed for circuits with high inrush currents, this breaker provides dependable overcurrent and short-circuit protection with a 6kA breaking capacity. Part of the DIN-T series, this unit is suitable for commercial and industrial switchboards requiring robust three-phase protection.

  • Rated current: 50A
  • Number of poles (total): 3
  • Trip curve: D
  • Rated voltage: 415V
  • Frequency: 50–60Hz
  • Voltage type: AC/DC
  • Rated short-circuit breaking capacity (Icn) at 230VAC: 6kA
  • Rated short-circuit breaking capacity (Icn) at 400VAC: 6kA
  • Rated short-circuit breaking capacity (Icu) at 230VAC: 20kA
  • Rated short-circuit breaking capacity (Icu) at 400VAC: 10kA
  • Max. rated operational voltage (Ue): 440V
  • Rated insulation voltage (Ui): 440V
  • Rated impulse withstand voltage (Uimp): 6kV

Click here for Data Sheet

SKU DTCB6350D
Brand NHP
