NHP Din-T MCB 16A 3 Pole 6KA C Curve

The NHP DTCB6316C is a 3 pole miniature circuit breaker (MCB) from the DIN-T range, rated at 16A with a C curve trip characteristic. Designed for dependable overcurrent and short-circuit protection, this breaker provides a 6kA breaking capacity and is suitable for both AC and DC installations. Ideal for commercial and industrial switchboards, the DTCB6316C offers reliable protection for three-phase circuits including lighting, power and general distribution applications.

  • Rated current: 16A
  • Number of poles: 3
  • Trip curve: C
  • Rated voltage: 415V
  • Frequency: 50–60Hz
  • Voltage type: AC/DC
  • Rated short-circuit breaking capacity (Icn) at 230VAC: 6kA
  • Rated short-circuit breaking capacity (Icn) at 400VAC: 6kA
  • Rated short-circuit breaking capacity (Icu) at 230VAC: 20kA
  • Rated short-circuit breaking capacity (Icu) at 400VAC: 10kA
  • Max rated operational voltage (Ue): 440V
  • Rated insulation voltage (Ui): 440V
  • Rated impulse withstand voltage (Uimp): 6kV

Click here for Data Sheet



SKU DTCB6316C
Brand NHP
