Legrand Inspyra 15A Vertical Single Power Point Grid

The Legrand Inspyra NR231010 is a 15A vertical single power point grid designed as a configurable higher-current outlet base within the Inspyra system. It supports connection of one compatible 15A device once completed with a suitable Inspyra coverplate, while angled screw terminals, enclosed terminals and a captive screw design help support secure and efficient installation.

Brand Legrand
Series Inspyra
15A vertical single power point grid
Grid-only format
15A rated single outlet
Suitable for one compatible higher-current device
Coverplate required to complete installation
Vertical mounting
AS/NZS 3112 Type I
1 socket outlet
1 switchable socket outlet
15A nominal current
240V nominal voltage
50-60Hz frequency
Screwed terminal connection
Angled screw terminal access
Enclosed terminals
Captive screw design
Enhanced contact protection
Insulated mounting
Plastic construction
Thermoplastic material
Matt surface finish
Mounting with screw
IP2X rated
IK07 impact resistance
74mm wide
108mm high
8mm deep
20mm built-in depth
Terminal capacity 1.5-6mm²
Loop through function
2 loop throughs
Operating temperature 0-40°C
Storage temperature -5-50°C

Click here for Data Sheet

SKU	NR231010
Brand	Legrand
