Legrand Inspyra 10A Horizontal Double Power Point Grid with USB A+C Charger

The Legrand Inspyra NR222090 is a 10A horizontal double power point grid with integrated USB-A and USB-C charging, designed to combine standard power access with convenient device charging within the Inspyra system. Its grid-only format includes the power and switch mechanisms, while the final coverplate is selected separately to complete the installation and match the desired interior finish.

Brand Legrand
Series Inspyra
10A horizontal double power point grid
Grid-only format
Double outlet configuration
Integrated USB-A charging port
Integrated USB-C charging port
Coverplate required to complete installation
Suitable for charging compatible USB devices
Recommended for smart watches, earphones and portable speakers
Not intended for high power or rapid charging of larger devices such as laptops
Horizontal mounting
AS/NZS 3112 Type I
2 socket outlets
2 switchable socket outlets
1 USB-A port
1 USB-C charging position
USB power supply maximum current 3A
USB output power 15W
10A nominal current
240V nominal voltage
50-60Hz frequency
Screwed terminal connection
Angled screw terminal access
Enclosed terminals
Enhanced contact protection
Insulated mounting
Plastic construction
Thermoplastic material
Matt surface finish
Mounting with screw
IP2X rated
IK07 impact resistance
108mm wide
74mm high
8mm deep
40mm built-in depth
Terminal capacity 1.5-6mm²
Loop through function
2 loop throughs
Operating temperature 0-40°C
Storage temperature -5-50°C

Click here for Data Sheet
