NHP DIN-T RCBO 16A 30mA 10kA 1P+N C Curve Type AC

The DSRCB1630P is a compact 1 Pole + Neutral RCBO from NHP’s DIN-T range, combining residual current protection and overcurrent protection in a single device. Designed for commercial, industrial and mining applications, this unit provides 16A protection with 30mA earth leakage sensitivity and a 10kA short-circuit breaking capacity.

This short body 36mm wide device is ideal for switchboard installations where space is limited while maintaining high performance and compliance with AS/NZS 61009

  • Rated current: 16A
  • Rated voltage: 240V AC
  • Rated leakage current: 30mA
  • Frequency: 50/60Hz
  • Short-circuit breaking capacity: 10kA
  • Trip curve: C curve
  • Leakage current type: Type AC
  • Tripping time: 40ms
  • Rated impulse withstand voltage (Uimp): 6kV
  • Rated insulation voltage (Ui): 440V

Click here for Data Sheet

SKU DSRCB1630P
Brand NHP
