NHP DIN-T Miniature Circuit Breaker 4A 1 Pole 6kA C Curve

The NHP DTCB6104C is a 1 pole miniature circuit breaker (MCB) from the DIN-T range, rated at 4A with a C curve trip characteristic. Designed for reliable protection of electrical circuits, this breaker provides 6kA short-circuit breaking capacity and is suitable for both AC and DC applications.

Engineered to meet AS/NZS 60898 and AS/NZS 60947-2 standards, the DTCB6104C delivers dependable overcurrent and short-circuit protection for residential, commercial and light industrial installations

Rated current: 4A
Number of poles: 1
Trip curve: C curve
Rated voltage: 240V
Frequency: 50–60Hz
Voltage type: AC/DC
Rated short-circuit breaking capacity (Icn) at 230VAC: 6kA
Rated short-circuit breaking capacity (Icn) at 400VAC: 6kA
Rated short-circuit breaking capacity (Icu) at 230VAC: 10kA
Rated insulation voltage (Ui): 440V
Rated impulse withstand voltage (Uimp): 6kV

Click here for Data Sheet

SKU	DTCB6104C
Brand	NHP
